Main
| range of product | AvatarOn A |
|---|---|
| product or component type | USB charger |
| mounting mode | Flush-mounted |
| integrated connection type | 2 USB port 5 V AC/DC, maximum load current: 2.4 A |
Complementary
| device presentation | Complete product |
|---|---|
| colour tint | Grey |
| surface finish | Matt |
| surface treatment | Painted |
| ambient air temperature for operation | -5…45 °C |
| ambient air temperature for storage | -5…60 °C |
| relative humidity | 0…95 % |
| [Ue] rated operational voltage | 110…220 V 50…60 Hz |
| input power | 12 W |
| maximum load current with 2 outputs used simultaneously | 2.4 A |
| material | PC (UL94 V-0) |
| screwdriver shape | Philips No 2 |
| clamping connection capacity | 0.5…4 mm² for solid or flexible cable(s) |
| wire stripping length | 12 mm |
| height | 69.3 mm |
| width | 46.6 mm |
| depth | 36 mm |
| embedding depth | 25 mm |
Environment
| standards | IEC 62368-1 |
|---|---|
| product certifications | IEC |
| IP degree of protection | IP20 |
Packing Units
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 53 g |
| Package 1 Height | 3.6 cm |
| Package 1 width | 4.66 cm |
| Package 1 Length | 7 cm |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 10 |
| Package 2 Weight | 607 g |
| Package 2 Height | 9.1 cm |
| Package 2 width | 13 cm |
| Package 2 Length | 25.5 cm |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 120 |
| Package 3 Weight | 7.929 kg |
| Package 3 Height | 30 cm |
| Package 3 width | 30 cm |
| Package 3 Length | 40 cm |
