iEM3555 energy meter – BACnet – 1 DI – 1 DO – multi-tariff – Rogowski coil
เอกสาร
ใบข้อมูลผลิตภัณฑ์
User guide
Instruction sheet
Catalogue
เอกสาร CAD
Product Environmental Profile
Main
| range | Acti 9 |
|---|---|
| range of product | Acti 9 iEM3000 |
| device short name | IEM3565 |
| product or component type | Energy meter |
Complementary
| poles description | 1P + N 3P + N 3P |
|---|---|
| type of measurement | Active and reactive energy Active and reactive power Current Voltage |
| metering type | Active, reactive, apparent energy (signed, four quadrant) |
| device application | Sub billing Partial meter Multi-tariff |
| accuracy class | Class 0.5S active energy conforming to IEC 62053-22 Class 0.5S active energy conforming to ANSI C12.20 |
| input type | Rogowski coil 50…5000 A |
| rated voltage | 100…277 V +/- 20 % 173…480 V +/- 20 % |
| network frequency | 50 Hz 60 Hz |
| technology type | Electronic |
| display type | LCD display |
| sampling rate | 32 samples/cycle |
| measurement current | 50…5000 A |
| maximum value measured | 99999999.9 kWh 99999999 MWh |
| tariff input | Tariff (4) |
| communication port protocol | BACnet at 9.6, 19.2, 38.4, 57.6, 76.8 kbauds |
| communication port support | Screw terminal block: RS485 |
| local signalling | Green indicator light: power ON Yellow flashing LED: accuracy checking alarm: overload |
| number of inputs | 1 digital 0…5 V/11…40 V 24 V DC |
| number of outputs | 1 digital (static) |
| output voltage | 5…40 V DC@50 mA |
| mounting mode | Clip-on |
| mounting support | DIN rail |
| connections – terminals | Current circuit: screw terminals 6 mm² cable(s) Voltage circuit: screw terminals 2.5 mm² cable(s) Input/output circuit: screw terminals 1.5 mm² cable(s) Communication: screw terminals 2.5 mm² cable(s) |
| tightening torque | Input/output circuit: 0.5 N.m Philips screwdriver Voltage circuit: 0.5 N.m Philips screwdriver Current circuit: 0.8 N.m pozidriv screwdriver Communication: 0.5 N.m Philips screwdriver |
| wire stripping length | Input/output circuit: 6 mm Voltage circuit: 8 mm Current circuit: 8 mm Communication: 7 mm |
| standards | IEC 61557-12 IEC 61036 UL 61010-1 IEC 61010 IEC 62053-21 IEC 62053-23 |
| product certifications | CE conforming to IEC 61010 (safety) CE conforming to EN 61557-12 (power monitor) CE conforming to IEC 61326-1 (EMC) CULus conforming to UL 61010 (safety) CULus conforming to ANSI C12.20 (sub-meter) EAC (sub-meter) RCM conforming to NMI M 6-1 (sub-meter) UL |
Environment
| IP degree of protection | IP40 front panel: conforming to IEC 60529 IP20 body: conforming to IEC 60529 |
|---|---|
| IK degree of protection | IK08 |
| pollution degree | 2 |
| relative humidity | 5…95 % at 36 °C |
| ambient air temperature for operation | -25…70 °C – IEC |
| ambient air temperature for storage | -40…85 °C |
| operating altitude | < 3000 m |
| colour | White |
| 9 mm pitches | 10 |
| width | 90 mm |
| height | 87 mm |
| depth | 69 mm |
Packing Units
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 323.0 g |
| Package 1 Height | 8.8 cm |
| Package 1 width | 9.8 cm |
| Package 1 Length | 10.5 cm |
| Unit Type of Package 2 | P06 |
| Number of Units in Package 2 | 240 |
| Package 2 Weight | 100.364 kg |
| Package 2 Height | 50 cm |
| Package 2 width | 80 cm |
| Package 2 Length | 60 cm |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 30 |
| Package 3 Weight | 11.483 kg |
| Package 3 Height | 30 cm |
| Package 3 width | 30 cm |
| Package 3 Length | 40 cm |
